Slimline Glazing
Frameless slimline glazing opens up new horizons and satisfies the highest expectations of exclusive architectural design.
Aesthetics and functionality The threshold-free installation of our systems creates a future-ready living environment, enhancing both the aesthetics and the comfort of the home. Special ball bearings and stainless-steel axles in enclosed SKF/RMB housings provide uniquely smooth running characteristics. A sliding door weighing 180 kg in total can be moved with less than 20 Nm (2 kg) of force. The glass elements can also be electrically operated if required. Reduction to the maximum The glazing is produced using thermally broken light-alloy system profiles. Made from a corrosion-resistant aluminium alloy (Al, Si, Mg 0.5), the extruded profiles are thermally insulated by rolled-in polyamide strips. The surface finish may be natural anodised, have a brushed stainless-steel appearance, or be powder-coated in a colour from the RAL, NCS or anthracite metallic mica ranges.
Uncompromising simplicity for the most exacting requirements Thanks to their slender, modular construction, our glazing systems are equally suitable for new-build and refurbishment projects, for large or small spans, and for façades or interiors. Even numerous exceptionally large sliding elements can be incorporated—co-ordinated with one another, disappearing silently into a partition wall, or sliding away from a corner without a supporting post. Even when closed, the system preserves an uninterrupted view from the light-filled room out into nature. The floor guide and surrounding frame profiles can be completely recessed into the floor and ceiling and into the adjoining walls. Innovative minimal windows – Swiss made FineLine is the next generation of slimline glazing. It is the world’s first slimline glazing system to meet the Minergie standard, combining the narrowest sightlines with unrivalled performance values. By using highly insulating glass with a Ug-value of 0.5 W/m2k, it is now possible to meet the broadest range of needs for individual clients with the highest expectations of architectural excellence. Exceptional acoustic-insulation values are achieved. Impact-resistant and bullet-resistant glazing can also be specified within the system. Running performance remains excellent even with very large sliding windows. Experience and expertise FineLine window systems are made by specialists in accordance with the finest standards of craftsmanship and using state-of-the-art technology. Yet even the best technology is of little use without the right people—people who understand their craft. Practical implementation Involve us in the design process at an early stage. The installation of frameless glazing must be allowed for in the structural calculations. We will be pleased to advise you on establishing the correct conditions. The premium window for architecture in its purest form Quality, design and passion come together in our slimline windows for exceptional requirements.
Security at the highest level FineLine provides optimum protection through monitored multi-point locking systems combined with suitably specified laminated glass linked to an alarm system or offering bullet resistance. Unrestricted views We remain uncompromising in the quality and functionality of our slimline glazing, with fully insulated, thermally broken construction: - minimal glazing profiles for the greatest possible admission of daylight - straightforward operation and maintenance - considerable flexibility in application - Automatic sliding-door operation with a drive integrated into the frame An eye for the whole and a love of detail Architecture takes on new dimensions: generosity and unity shape the interior. Precision and perfection define the details. With the exception of the slender glazing bars, the view remains entirely unrestricted.
